Shawn Flanges, located in Houston, USA, has made a name for itself as a leading manufacturer and supplier of BLRF (Blind Raised Face) Flanges. These flanges are celebrated for their exceptional performance in pressure-retaining applications where it’s crucial to seal off pipeline ends. With a raised face design, they ensure a secure fit for gaskets, providing a tight seal. Shawn Flanges offers these flanges in a variety of materials, including carbon steel, stainless steel, alloy steel, and exotic alloys, all crafted to meet ANSI, ASME, DIN, and EN standards. They’re widely utilized across sectors like oil & gas, petrochemicals, water treatment, and power generation, where high-integrity systems are essential.
BLRF Flanges from Shawn Flanges are crafted from a selection of materials, including ASTM A105 (carbon steel), ASTM A182 F304/F316 (stainless steel), and A694 F52–F70 (high-yield alloys). While the mechanical properties can differ by grade, they generally provide impressive tensile strength ranging from 485 to 750 MPa and yield strength from 250 to 600 MPa, along with excellent impact resistance and pressure containment. The raised face design not only enhances gasket compression but also boosts sealing effectiveness, even under varying pressure and temperature conditions. These flanges come in multiple pressure classes, from 150 to 2500, catering to a wide array of industrial needs.
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
|---|---|
| BLRF Flange Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS SP44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| BLRF Flange Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| BLRF Flanges Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| BLRF Flange | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| BLRF Flange UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| BLRF Flange EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| BLRF Flanges Production technique | Forged, Heat treated and machined |
| BLRF Flanges Connect Type / Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| BLRF Flange Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| BLRF Flanges Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| BLRF Flange Origin | Indian / West Europe / Japan / USA / Korean |
| Manufacturer of BLRF Flange | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM A182 F316 Stainless Steel Flanges |
| BLRF Flange Uses & application | Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids. |
| BLRF Flanges Export to | Ireland, Singapore, Indonesia, Ukraine, Saudi & Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Oman, Dubai, Peru, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Shawn Flanges, a leading supplier in Houston, USA, offers an extensive selection of BLRF Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Shawn Flanges’ BLRF Flanges are widely used in piping systems that require secure closures, inspection access, or potential future extensions. They’re commonly found at the ends of pipelines, valves, or pressure vessels, making them perfect for oil & gas pipelines, chemical plants, water distribution systems, and thermal power stations. Thanks to their raised face, they provide a tight seal, making them suitable for high-pressure and high-temperature applications. Additionally, BLRF flanges are essential during hydrotesting and system shutdowns. Shawn Flanges guarantees precise dimensions and consistent quality, delivering BLRF flanges that meet global standards and perform reliably.
| ASME/ANSI B16.5 | BLRF Flange |
| PRESSURE CLASS | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| DIN EN 1092-1 Face Dimensions | PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400 |
| BS 4504 SEC 3.1, BS 4504[PART 1], BS 1560 BOSS | BLRF Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Yes, we offer custom sizes for BLRF Flanges to meet specific project needs. Our team at Shawn Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shawnflanges.us.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
