Monel Socket Weld Flanges are mainly made up of nickel (63-70%) and copper (28-34%), along with small amounts of iron, manganese, carbon, and silicon. They show remarkable resistance to acids, alkalis, and seawater, even at elevated temperatures. Typically, the tensile strength ranges from 550-620 MPa, with a yield strength of about 240 MPa and an elongation of roughly 35%. The hardness is between 70–100 HB. These flanges provide outstanding mechanical strength and ductility, making them perfect for use in extreme pressure, thermal cycling, and corrosive environments.
Monel Socket Weld Flanges are mainly made up of nickel (approximately 63%) and copper (roughly 30%), along with trace amounts of iron, manganese, carbon, and silicon. This distinctive blend provides remarkable resistance to seawater, acids, and alkaline environments. On the mechanical side, these flanges boast high tensile strength, impressive yield strength, and exceptional hardness, all while maintaining good ductility. Their outstanding toughness across a wide temperature range and excellent corrosion resistance make them perfect for high-pressure and aggressive conditions, ensuring reliable performance and longevity in critical service applications.
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 AS 2129: Table D; Table E; Table H ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48 ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 American standard (ANSI) German (DIN) British standard (BS) DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM B564 K500 Monel Flanges The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Grades | Monel 400, K500 |
Shawn Flanges, a leading supplier in Houston, USA, offers an extensive selection of Monel Socket Weld Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Monel Socket Weld Flanges find extensive use in industries that demand corrosion resistance and durability. They are particularly popular in marine engineering, offshore oil drilling, and shipbuilding, thanks to their ability to endure seawater environments. In the chemical and petrochemical sectors, these flanges play a crucial role in managing acidic and alkaline solutions, ensuring safety and reliability. They are also essential in heat exchangers, power generation plants, and gas processing systems where strong, leak-proof connections are a must. Their strength and resistance to high temperatures make them vital for critical applications across various industrial sectors.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
| Monel K500 | 2.4375 | N05500 | – | – | – | – | – |
Yes, we offer custom sizes for Monel Socket Weld Flanges to meet specific project needs. Our team at Shawn Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shawnflanges.us.
Monel Socket Weld Flanges find extensive use in industries that demand corrosion resistance and durability. They are particularly popular in marine engineering, offshore oil drilling, and shipbuilding, thanks to their ability to endure seawater environments. In the chemical and petrochemical sectors, these flanges play a crucial role in managing acidic and alkaline solutions, ensuring safety and reliability. They are also essential in heat exchangers, power generation plants, and gas processing systems where strong, leak-proof connections are a must. Their strength and resistance to high temperatures make them vital for critical applications across various industrial sectors.
