Shawn Flanges is a reliable manufacturer and supplier located in Houston, USA, with a focus on high-performance Titanium Plate Flanges. With years of experience and a strong dedication to quality, Shawn Flanges provides products designed to meet the toughest industrial standards. Our Titanium Plate Flanges are well-known for their outstanding corrosion resistance, lightweight design, and durability, making them perfect for critical applications. We serve a variety of industries, including aerospace, marine, petrochemical, and medical, offering custom sizes and finishes to meet specific needs. Our unwavering commitment to precision and customer satisfaction has helped us build a solid reputation in both domestic and international markets.
Titanium Plate Flanges are mainly made from commercially pure titanium or titanium alloys like Grade 2 and Grade 5 (Ti-6Al-4V), which are celebrated for their excellent corrosion resistance and biocompatibility. These flanges boast high tensile strength, reaching up to 950 MPa for Grade 5, along with a low density of about 4.5 g/cm³, making them both robust and lightweight. They also offer remarkable fatigue resistance and thermal stability, with a melting point around 1668°C. These mechanical properties make them perfect for challenging and corrosive environments across various industrial applications.
| Specifications | ASTM B381 / ASME SB381 |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Grades | Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Size | 1 / 2” to 18″ |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Flange Type | Plate Flanges |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
Shawn Flanges, a premier supplier in Houston, USA, specializes in high-quality Titanium Plate Flanges. They are valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
Titanium Plate Flanges are extensively used in industries that require high strength, corrosion resistance, and weight efficiency. In aerospace, they play a crucial role in airframes and engine components where performance and weight savings are essential. The marine and offshore industries rely on them for underwater pipelines due to their resistance to seawater corrosion. In the chemical and petrochemical sectors, they are the go-to choice for handling corrosive fluids. Their biocompatibility makes them ideal for surgical tools and implants in the medical field. Additionally, they are utilized in power plants, desalination systems, and high-performance automotive parts.
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
| Titanium Gr. 5 | 3.7165 | N56400 |
Yes, we offer custom sizes for Titanium Plate Flanges to meet specific project needs. Our team at Shawn Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shawnflanges.us.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
