Shawn Flanges is a well-respected manufacturer and supplier based in Houston, USA, known for providing top-notch Carbon Steel Slip On Flanges that prioritize reliability, easy installation, and long-lasting performance. These flanges are a go-to choice in moderate to high-pressure piping systems where precise alignment and secure connections are crucial. Crafted from high-quality carbon steel and utilizing advanced production methods, they boast impressive mechanical strength, durability, and resistance to wear and corrosion. Industries like oil & gas, petrochemical, power generation, shipbuilding, and water treatment trust Shawn Flanges for their dependable Carbon Steel Slip On Flanges, ensuring safe and efficient piping operations.
Typically, Carbon Steel Slip On Flanges are made from premium carbon steel, which contains controlled levels of carbon, manganese, and other trace elements to boost strength, hardness, and durability. On a mechanical level, they deliver good tensile and yield strength, along with adequate elongation and toughness, making them suitable for moderate to high-pressure systems. Their slip-on design allows for easy pipe insertion into the flange before welding, ensuring precise alignment, minimal stress concentration, and a secure, leak-proof joint. This feature also facilitates repeated maintenance and inspections.
| Specification | ASTM A694 / ASME SA105 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MCarbon S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| PRESSURE Rating ANSI | Class 150 LBS, 300 LBS, a105 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| PRESSURE Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Precarbon-steel machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM A694 Lf2 Carbon Steel Flanges |
| Grades | Carbon Steel a105, Lf2, f42, f52, f56, f60, f65, f70, f80, A36, IS2062 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Shawn Flanges, a leading supplier in Houston, USA, offers an extensive selection of Carbon Steel Slip On Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
These flanges are widely utilized in industries that require straightforward installation and secure connections. You’ll often find them in oil refineries, chemical plants, gas distribution pipelines, water treatment systems, and shipbuilding. Their design promotes smooth welding and alignment while guaranteeing a tight, leak-proof seal. Ideal for transporting liquids, gases, and steam under moderate to high-pressure conditions, these flanges offer a durable and cost-effective solution. With their strength, reliability, and versatility, Carbon Steel Slip On Flanges are a top choice for a variety of industrial piping applications.
| ASME/ANSI B 16.5 | Slip on Flange |
| PRESSURE CLASS | 150, 300, a105, a105, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | Blind Flange [Series A & B],Welding Neck Flange |
| PRESSURE CLASS | 75, 150, 300, a105, a105, 900 |
| ASME/ANSI B 16.36 | Slip on Flange |
| PRESSURE CLASS | 300, a105, a105, 900, 1500, 2500 |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Hubbed Slip-On |
| PRESSURE CLASS | PN 2.5 TO PN a105 |
| BS 1560 BOCarbon | Hubbed Slip-On Hubbed Threaded |
| PRESSURE CLASS | 150, 300, a105, a105, 900, 1500, 2500 |
| BS10 | Plate Slip-On Flange, Slip-On Bocarbon-steel Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Yes, we offer custom sizes for Carbon Steel Slip On Flanges to meet specific project needs. Our team at Shawn Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shawnflanges.us.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
