Shawn Flanges, located in Houston, USA, stands out as a top manufacturer and supplier of API Flanges, delivering high-quality flange solutions tailored for high-pressure and critical service applications in the oil and gas sector. These flanges are crafted with meticulous attention to the American Petroleum Institute (API) specifications, ensuring they can withstand extreme pressure, temperature, and corrosive environments. Renowned for their precision, durability, and leak-proof performance, API Flanges from Shawn Flanges are a trusted choice across upstream, midstream, and downstream operations. Thanks to cutting-edge production technology, stringent quality control, and prompt global delivery, Shawn Flanges guarantees safe, reliable, and long-lasting performance for demanding industrial projects.
Typically, API Flanges are made from high-strength carbon steel, alloy steel, or stainless steel, depending on the specific service conditions. Their chemical makeup includes carbon, manganese, silicon, phosphorus, sulfur, and various alloying elements like chromium, nickel, and molybdenum, which together provide outstanding mechanical strength, toughness, and resistance to high-pressure situations. On a mechanical level, API Flanges boast impressive tensile and yield strength, excellent ductility, impact resistance, and dimensional stability, ensuring secure connections in critical oilfield equipment.
| Specifications | BS 10 Flanges |
|---|---|
| BS Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange BS Sorf Flange BS Table Flanges DIN 2566 pn10 BS Large Diameter Flange BS Threaded Flanges BS Blind Flanges BS Plate Flanges BS Weld Neck Flanges BS Loose Flanges BS Orifice Flanges BS Slip-On Flanges BS Lap Joint Flanges BS Socketweld Flanges BS AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for BS 10 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| BS 10 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Shawn Flanges, a premier supplier in Houston, USA, specializes in high-quality API Flange, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
These flanges are widely utilized in oil and gas exploration, drilling, production, refining, and pipeline systems. They play a crucial role in wellhead assemblies, choke and kill manifolds, drilling equipment, subsea systems, and other high-pressure applications where safety and performance are paramount. API Flanges create leak-proof connections between pipes, valves, pumps, and other components, maintaining their integrity even in the harshest offshore and onshore conditions. With their robust construction, compatibility with API standards, and straightforward installation, they are the go-to choice for industries that demand reliable, high-pressure flange solutions that meet international safety and quality standards.
| BRITISH BS 10 TABLE D FLANGE | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| N.B. SIZE | D | K | L | A | C | N1 | N2 | B | H1 | H2 | R1 | R2 | HOLES | |
| IN | mm | |||||||||||||
| ½” | 15 | 95.3 | 66.8 | 14.5 | 21.3 | 4.8 | 27.0 | 33.3 | 22.4 | 9.5 | 22.2 | 6.4 | 1.6 | 4 |
| ¾” | 20 | 101.6 | 73.2 | 14.5 | 26.7 | 4.8 | 33.3 | 38.1 | 27.7 | 11.1 | 22.2 | 6.4 | 1.6 | 4 |
| 1″ | 25 | 114.3 | 82.6 | 14.5 | 33.5 | 4.8 | 42.9 | 47.6 | 34.6 | 11.1 | 22.2 | 6.4 | 1.6 | 4 |
| 1 ¼” | 32 | 120.7 | 87.4 | 14.5 | 42.2 | 6.4 | 49.2 | 55.6 | 43.2 | 11.1 | 25.4 | 6.4 | 1.6 | 4 |
| 1 ½” | 40 | 133.4 | 98.6 | 14.5 | 48.3 | 6.4 | 58.7 | 61.9 | 49.5 | 12.7 | 28.6 | 6.4 | 1.6 | 4 |
| 2″ | 50 | 152.4 | 114.3 | 17.5 | 60.5 | 7.9 | 69.9 | 74.6 | 62.0 | 12.7 | 28.6 | 6.4 | 1.6 | 4 |
| 2 ½” | 65 | 165.1 | 127.0 | 17.5 | 73.2 | 7.9 | 82.6 | 90.5 | 74.7 | 15.9 | 31.8 | 6.4 | 1.6 | 4 |
| 3″ | 80 | 184.2 | 146.1 | 17.5 | 88.9 | 9.7 | 101.6 | 106.4 | 90.7 | 15.9 | 34.9 | 6.4 | 1.6 | 4 |
| 3 ½” | 88 | 203.2 | 165.1 | 17.5 | 101.6 | 9.7 | 114.3 | 119.1 | 103.4 | 17.5 | 34.9 | 6.4 | 1.6 | 4 |
| 4″ | 100 | 215.9 | 177.8 | 17.5 | 114.3 | 9.7 | 130.2 | 133.4 | 116.1 | 19.1 | 41.3 | 9.5 | 3.2 | 4 |
| 5″ | 125 | 254.0 | 209.6 | 17.5 | 141.2 | 12.7 | 152.4 | 160.3 | 143.8 | 19.1 | 44.5 | 9.5 | 3.2 | 8 |
| 6″ | 150 | 279.4 | 235.0 | 17.5 | 168.4 | 12.7 | 184.2 | 185.7 | 171.7 | 19.1 | 47.6 | 9.5 | 3.2 | 8 |
| 8″ | 200 | 336.6 | 292.1 | 17.5 | 219.2 | 12.7 | 241.3 | 241.3 | 221.5 | 22.2 | 50.8 | 9.5 | 3.2 | 8 |
| 10″ | 250 | 406.4 | 355.6 | 22.2 | 273.1 | 16.0 | 292.1 | 298.5 | 276.4 | 27.0 | 63.5 | 9.5 | 3.2 | 8 |
| 12″ | 300 | 457.2 | 406.4 | 22.2 | 323.9 | 19.1 | 342.9 | 349.3 | 325.9 | 28.6 | 69.9 | 9.5 | 4.8 | 12 |
| 14″ | 350 | 527.1 | 469.9 | 25.4 | 355.6 | 22.2 | 406.4 | – | 359.2 | – | 73.0 | 9.5 | 4.8 | 12 |
| 16″ | 400 | 577.9 | 520.7 | 25.4 | 406.4 | 22.2 | – | – | 410.5 | – | – | – | – | 12 |
| 18″ | 450 | 641.4 | 584.2 | 25.4 | 457.2 | 25.4 | – | – | 461.8 | – | – | – | – | 12 |
| 20″ | 500 | 704.9 | 641.4 | 25.4 | 508.0 | 28.6 | – | – | 513.1 | – | – | – | – | 16 |
| 24″ | 600 | 825.5 | 755.7 | 28.7 | 609.6 | 31.8 | – | – | 616.0 | – | – | – | – | 16 |
